Laboratory infrastructure

The ISC has a modern laboratory infrastructure for sophisticated R&D work and prototype production.

Electronics lab with measurement equipment, workstations and large windows.

Equipment:

Audio interfaces and microphones
Digital Oscilloscopes up to 80 GS/s, 4CH, 4 GHz
Spectrum analyzers / RTSA up to 26 GHz
Network analyzers up to 20 GHz
Field Strength Meters up to 3 GHz
Signal generators / AWG up to 6 GHz
Small mechanical workshop and 3D printer
SMD workstation, reflow and vapor phase soldering oven
Manual assembly systems
GPS Simulator / Generator
Climatic cabinet 37l, -40 - 180°C
Thermal imaging camera
SW tools e.g. CST Studio, Altium, Matlab, diverse MCU & DSP IDEs

Antenna measurement room / Absorber chamber

Inner dimensions (LxWxH) 3.7 x 1.9 x 1.8 m
Frequency range 500 MHz - 110 GHz

specification (PDF 85 kB) contact: S.Schüller (scam@zhaw.ch) Tel. 058 934 7511

The laboratories and offices of the ZHAW Institute of Signal Processing and Wireless Communications (ISC) are located in the TN and TS buildings.
